1MP USB3.0 60FPS 120FPS Global Shutter Camera Module With Free Driver
Global Shutter: By exposing the entire scene at the same time, all pixels of the sensor collect light at the same time and expose it at the same time. That is, at the beginning of the exposure, the sensor begins to collect light, and at the end of the exposure, the ray collection circuit is cut off. The sensor value is then read out as a picture
HBVCAM-2237-2 V11 is OV9281 1MP HD Black &White Dual Camera module, the Frame rate can reach to 120FPS for single camera resolution, can reach to 60FPS for dual camera resolution. The camera can be used Ranging applications, Three-dimensional Reconstruction Vision Applications
Module No. | HBVCAM-W2237-2 V11 |
Module Size | 156mm × 36mm × 16.30mm±0.5MM |
Temperature (Operation) | -30°C to 70°C |
Temperature (Stable Image) | 0°C to 50°C |
Assembly technique | SMT (ROSH) |
Focus | Fixed |
Object distance | 30CM-infinity |
Resolution | 600LW/PH (Center) |
PCB printing ink | Black |
interface | USB 2.0 |
Power suuply | USB bus power |
supply voltage | DC 5V±5% |
Maximum Power consumption | 1000 mW |
Operating system request | Win XP/win 7、8 / vista /android 4.0/ mac /Linux with uvc |
Sensor | OV9281 (1/4” ) |
Seneor Package | CSP,Bare Die |
Maximum resolution | 2560*720 |
Sensitivity | 1300mV /（lux-sec） |
Pixel Size | 3µm x 3µm |
Maximum Image Transfer Rate | MJPEG 320x232 120FPS / YUY2 320x232 30FPS MJPEG 320x240 120FPS / YUY2 320x240 30FPS MJPEG 640x240 100FPS / YUY2 640x240 30FPS MJPEG 640x392 120FPS / YUY2 640x392 30FPS MJPEG 640x400 120FPS / YUY2 640x400 30FPS MJPEG 640x472 120FPS / YUY2 640x472 30FPS MJPEG 640x480 120FPS / YUY2 640x480 30FPS MJPEG 800x592 120FPS / YUY2 800x592 20FPS MJPEG 800x600 120FPS / YUY2 800x600 20FPS MJPEG 1280x712 120FPS / YUY2 1280x712 5FPS MJPEG 1280x720 120FPS / YUY2 1280x720 5FPS MJPEG 1280x400 120FPS / YUY2 1280x400 20FPS MJPEG 1280x480 100FPS / YUY2 1280x480 10FPS MJPEG 1600x600 100FPS / YUY2 1600x600 10FPS MJPEG 2560x720 60FPS / YUY2 2560x720 5FPS Dual Resolution: MJPEG 640x240 /MJPEG 1280x400 /MJPEG 1280x480 /MJPEG 1600x600/ MJPEG 2560x720 (the same as YUY2 Format)
|
S/N Ratio | 38 db |
Max Dynamic Range | 68 db |
Shutter type | Global shutter |
AGC/AEC/Whiter balance | Auto |
Output Formats | YUY2/MJPEG |
Microphone | Support |
Lens Construction | 2G2P |
F/No | 2.2 |
EFL | 2.1 mm |
FOV | 100° |
TV Distortion | <5% |
Relative Illumination (Sensor) | 70% |
IR Filter | 650±10nm |
Module Package | Anti-electrostatic tray |
